XPEBAM-L1-0000-00901 - CREELED, INC. - LED XLAMP XPE2 AMBER 590NM SMD | |
Packaging | Cut Tape (CT) |
Package / Case | 1414 (3535 Metric) |
Color | Amber |
Wavelength | 590nm (585nm ~ 595nm) |
Size / Dimension | 0.136" L x 0.136" W (3.45mm x 3.45mm) |
Mounting Type | Surface Mount |
Voltage - Forward (Vf) (Typ) | 2.2V |
Current - Test | 350mA |
Viewing Angle | 130° |
Current - Max | 1A |
Supplier Device Package | SMD |
Lumens/Watt @ Current - Test | 109 lm/W |
Height - Seated (Max) | 0.094" (2.39mm) |
Temperature - Test | 25°C |
Luminous Flux @ Current/Temperature | 84lm (81lm ~ 87lm) |
